Conveyor Belts
Bucket Elevator Belt
Product Features
- High Tensile Strength
- Excellent Dimensional Stability
- Superior Bonding Strength
- Abrasion & Impact Resistance
- Custom Bucket Hole Design
- High Temperature Tolerance
- Low Maintenance & Long Service Life
- Anti-static & Fire-resistance Options
CARCASS Construction
SW Type
SW-type Bucket Elevator Belts use woven E-cords—straight warp steel cords with built-in elasticity for shock absorption and dynamic load handling. The warp cords offer tensile strength, while rigid weft cords, precisely tied through specialized weaving, ensure dimensional stability. This construction delivers high impact resistance and load capacity, making SW belts ideal for high-lift vertical conveying in demanding industrial environments like cement, mining, and bulk material handling.
| Strength | Belt Construction | Working Temperature |
| SW630 RE | 3+3 mm | Up to 200°C |
| SW800 RE | 4+4 mm | Up to 200°C |
| SW1000 RE | 4+4 mm | Up to 200°C |
| SW1250 RE | 4+4 mm | Up to 200°C |
| SW1400 RE | 4+4 mm | Up to 200°C |
| SW1600 RE | 4+4 mm | Up to 200°C |
| SW1800 RE | 4+4 mm | Up to 200°C |
| SW2000 RE | 4+4 mm | Up to 200°C |
| SW2500 RE | 4+4 mm | Up to 200°C |
Advantages of SW Type Construction:
- Exceptional Flexibility
- Low Permanent Elongation
- Enhanced Impact Resistance
- Maximum Rubber Penetration
- Corrosion Protection
